◎ CH1
- output：5V 4A
- Tol：±2%
- R&N：80mV
- Effi.：78%
◎ CH2
- output：15V 1.5A
- Tol：+8, -4%
- R&N：120mV
◎ CH3
- output：-15V 0.5A
- Tol：：±2%
- R&N：120mV
(負載需高於下限)
-----------------------------------------------------------------------------------
AC/DC 機殼型(Enclosed Type)交換式電源供應器 G3 系列 RT-50
◎ 小型化
◎ 高信賴度，可承受5G震動與70℃高工作環溫，全機使用105℃高壽命電解電容，可承受300VAC突波輸入達5秒
◎ 適合使用于較嚴苛的工作環境

◎ 注意事項：
	1.鐵殼上方有貼上黃色標籤的規格是表示輸入電壓AC110V /220V需開關切換，開關位置就在箭頭尖處的洞哩，利用小起子切換。 (出廠預設是220V)

　
　
◎ AC input voltage range：88~264VAC, 124~370VDC
◎ AC inrush current (max.)：Cold start, 40A at 230VAC
◎ DC adjustment range：±10% by potential meter for single output; CH1 -5%~+10% by potential meter for multiple output
◎ Overload protection：110%~150% hiccup mode, auto-recovery
◎ Over voltage protection：115%~135% rated output voltage, hiccup mode, auto-recovery
◎ Withstand voltage：I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC, 1 minute
◎ Working temperature：-20℃~+70℃ (refer to the derating curve for different models)
◎ Vibration：10~500Hz, 5G 10min/1 cycle, period for 60 min each along X, Y, Z axes
◎ Safety standards：UL60950-1, TUV EN60950-1 approved
◎ EMC standards EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, ENV50204, EN61000-6-2 (EN50082-2) (35~150W)
◎ Connection：Terminal block for input and output
