◎ 型式：VH Type
◎ Inner Dia.：16mm
◎ 電流範圍：5Arms
◎ 輸出電壓： 0~10V DC (Average) / 0 ~ Rated Current，15V DC Limiter built-in
◎ Max. Allowable Current：100% (Continuous)，150% (1min.)
◎ Output Voltage：± 2% FS Dynamic Range 1:100 at 50/60Hz Sinewave
◎ Output Impadance：23 kΩ
◎ Output Ripple：Within 5% Output Current
◎ Response Time：300m Sec
◎ Insulation Resistance：DC500V/100MΩ or more(betweem core and Output terminals)
◎ Dielectric Strength：AC2000V/1min.(betweem core and Output terminals)
◎ Latch/Unlatch：about 150 times
◎ Output Terminals： 2 x M3 Screw, with Terminals cover
◎ Tightening Torque：0.3N.m
◎ Operating Conditions： -20℃~+50℃, ≤85%RH, No condensation, In-house & Any direction installable
◎ Storage Conditions： -30℃~+90℃, ≤85%RH, No condensation
◎ Weight：75g
