顏色︰亮灰色 Light Grey 透明上蓋 clear LID
材質︰聚碳酸酯 Polycarbonate
Size︰160(W) x 160(D) x 60(H)mm
---------------------------------------------
除固定孔外均未開孔
塑膠製機盒皆有通過 SGS RoHS 規範

◎ Polycarbonate material :
◎ Moulded In : Light Grey.
◎ Operating temperature : -40℃ to 120℃
◎ Clear lid is available on request
◎ High impact ABS material:
◎ Mould in : dark gray.
◎ Suggested Operating Temperature : -20℃ to 80℃
◎ The lid and base incorporate a tongue and groove sealing system with a neoprene gasket
◎ Wall mounting holes and lid fixing screws are outside the sealing area thus preventing the
ingress of moisture and dust
◎ Designed to IP 65 of IEC 529 and nema 4 (dust and hoseproof)
◎ Available with clear or light gray LIDS
◎ Internal guide slots for mounting PCB assemblies vertically
◎ Bosses on internal base allow fixing of PCB's horizontally or connection of terminals, etc into threaded brass inserts
◎ Lid fixing screw are M-4 stainless steel (non-magnetic) into threaded brass inserts
ORDERING INFORMATION :
◎ Above stock number are for polycarbonate enclosures with light gray lids and include lid fixing screws, brass inserts and neoprene gasket
◎ Add the following letters after the above stock numbers to order clear lids(C)
