◎ 晶片：ASIX-99100
◎ 類型：PCI Express
◎ 輸出端：4埠RS232
◎ 工作溫度：0°C～50°C
◎ 儲存溫度：0°C～100°C
◎ 濕度：10% ~ 90% RH
◎ 應用：並行 / 印表機端口的應用程序、附加I / O卡並行、嵌入式系統用於I / O擴展
◎ 完全符合PCI Express基礎1.0a規範
◎ 相容PCI Express卡應用要求
◎ 支援RS232，RS485和RS422模式
◎ Utilises 100-MHz Differential PCI Express Common Reference Clock
◎ Bi-directional speeds from 50 bps to 16 Mbps/Port
◎ Full Serial modem control
◎ Supports Hardware, Software flow control
◎ 5, 6, 7, 8 and 9-bit Serial format support
◎ Even, Odd, None, space & Mark parity supported
◎ Custom BAUD Rates supported with external clock or by programming internal PLL
◎ On Chip 256 Byte depth FIFOs in Transmit, Receive path of each Serial Port
◎ Supports remote wake up and power management features
◎ Serial Port transceiver shutdown support
◎ Supports Slow IrDA on all Serial Ports IEEE1284
◎ 並行端口IEEE 1284相容並行端口接口，支援SPP / PS2 / EPP / ECP模式和centronics接口並行端口的速率高達1.5Mbps
◎ NOS軟體支援：Windows 98 / ME / NT4.0 / 2000 / XP / Vista / Win7 / Win8 / Win10 / Server2003 / Linux
◎ 尺寸：主板約 120(L) x 80(W) x 22(H)mm / 排線長：約10cm
